Debug, Tweak and fine-tune your DIY electronics projects
This hands-on guide shows, step by step, how to build, debug, and troubleshoot a wide range of analog electronic circuits. Written by electronics guru Ronald Quan,
Troubleshooting Electronic Circuits: A Guide to Learning Analog Circuits
clearly explains proper debugging techniques as well as testing and modifying methods. In multiple chapters, poorly-conceived circuits are analyzed and improved. Inside, you will discover how to design or re-design high-quality circuits that are repeatable and manufacturable.
Coverage includes:
• An introduction to electronics troubleshooting
• Breadboards
• Power sources, batteries, battery holders, safety issues, and volt meters
• Basic electronic components
• Diodes, rectifiers, and Zener diodes
• Light emitting diodes (LEDs)
• Bipolar junction transistors (BJTs)
• Troubleshooting discrete circuits (simple transistor amplifiers)
• Analog integrated circuits, including amplifiers and voltage regulators
• Audio circuits
• Troubleshooting analog integrated circuits
• Ham radio circuits related to SDR
• Trimmer circuits, including the 555 chip and CMOS circuits
